Flexible square air duct for ventilation and air conditioning

Flexible PVC air duct with a spiral high-carbon steel wire frame.
Combination name Code EAN Availability Price VAT excl. Preis VAT incl. Add to cart
Dalap AS-110x55/1 4526 4250622610378 30+ pcs. 2.90 € 3.45 €
shopping_cart
Dalap AS-110x55/1,5 4527 4250622610385 30+ pcs. 3.99 € 4.75 €
shopping_cart
Dalap AS-110x55/3 4523 4250622610392 30+ pcs. 7.02 € 8.35 €
shopping_cart
Dalap AS-204x60/0,5 4531 4250622622227 ON REQUEST 2.21 € 2.63 €
shopping_cart
Dalap AS-204x60/1 4528 4250622610408 30+ pcs. 3.78 € 4.50 €
shopping_cart
Dalap AS-204x60/3 4524 4250622610415 10+ pcs. 9.24 € 11.00 €
shopping_cart

APPLICATION

Plastic square flexible air ducts are used for supply and exhaust vents of public, residential and industrial ventilation systems. The ideal solution for ventilation of living quarters and office premises.

DESIGN

The flexible PVC air ducts with spiral high-carbon steel wire frame Flame-retardant, self-extinguishing.

CUSTOMS CODE: 39173100

PLASTIC SQUARE AIR DUCT_CZ

CZ_Prohlášení o shodě

PLASTIC SQUARE AIR DUCT_DE

DE_Konformitaetserklaerung

PLASTIC SQUARE AIR DUCT_SK

SK_Vyhlásenie o zhode

PLASTIC SQUARE AIR DUCT_PL

PL_Deklaracja zgodności

PLASTIC SQUARE AIR DUCT_EN

EN_Declaration of conformity


ModelDimensions (mm)
range of sizePVC air
duct base		air duct
wire		max.
length		Weight (kg)Downloads
 AS-110x55/1 110x55 0,065 0,8 1000 0,092 Detail
 AS-110x55/1,5 110x55 0,065 0,8 1500 0,121 Detail
 AS-110x55/3 110x55 0,065 0,8 3000 0,278 Detail
 AS-204x60/0,5 204x60 0,065 0,8 500 0,096 Detail
 AS-204x60/1 204x60 0,065 0,8 1000 0,127 Detail
 AS-204x60/3 204x60 0,065 0,8 3000 0,370 Detail
